Features:
- 4-POLE 12-SLOT design boasts exceptional EFFICIENCY and produces LESS HEAT
- Oversized gold plated solder tabs for LESS RESISTANCE and easy soldering
- QUIETSENSE™ Technology shields magnetic field noise generated from the motor coils and keeps motor and ESC in sync at all times
- HIGHER PRECISION and MORE EFFICIENT startups
- OPTIMIZED design eliminates the need for mechanical timing adjustments
- Sensor alignment method delivers uniform timing and torque in both directions, automatically
- REBUILDABLE design allows users to replace front end bell with bearings or rotors with shaft
- ROAR standard sensor port and labeled connections
- High strength 180°C neodymium sintered magnets
- High quality, temperature-stabilized sensors
- High-purity, high-temperature copper windings
- Hardened stainless steel shaft
- 10 AWG high strand wire with silicone insulation
- Kevlar wrapped rotor
- 6061-T6 Billet aluminum heatsink can
- High RPM NMB oversized bearings
- High quality 0.2mm steel laminations
- Low resistance gold plated bullet connectors
Specifications:
Input Voltage Range: 2-6S LiPoKv: 2200Max. RPM: 60,000Length: 75.4mmDiameter: 40mm (41.1mm w/fins)Weight (w/wires): 429 g / 15.1ozShaft Size: 20mmDiameter: 5mmMounting Hole Specifications: M3 & M4 @ 25mmCooling Fan: Optional - Coming SoonConnectors: 6.5mm male Castle Bullet ConnectorsApplication Guidelines: Ideal for 1:8 scale off-road and on-road vehicles as well as 1:10 scale Monster Trucks up to 15lbs.Recommended ESC(s): Mamba Monster XMax. Recommended Vehicle Weight: Up to 15lbsTech Notes: Running modes: SMARTSENSE™, Sensored, Sensorless
